IP Address Filter (UE9 Only)
Sets a list of up to five IP addresses that are the only IP addresses that can connect to the UE9. Any unused Addresses can be set to 0xFFFFFFFF (255.255.255.255). If IP #0 is set to 0xFFFFFFFF than the feature is disabled and any IP address can connect.
Command: |
|
Byte |
|
0 | Checksum8 |
1 | 0×78 |
2 | 0×0B |
3 | 0xAF |
4 | Checksum16 (LSB) |
5 | Checksum16 (MSB) |
6 | Write |
7 | Reserved |
8-11 | IP #0 |
12-15 | IP #1 |
16-19 | IP #2 |
20-23 | IP #3 |
24-27 | IP #4 |
|
|
Response: |
|
Byte |
|
0 | Checksum8 |
1 | 0×78 |
2 | 0×0B |
3 | 0xAF |
4 | Checksum16 (LSB) |
5 | Checksum16 (MSB) |
6 | Write |
7 | ErrorCode |
8-11 | IP #0 |
12-15 | IP #1 |
16-19 | IP #2 |
20-23 | IP #3 |
24-27 | IP #4 |
Write: Set to non-zero if new values should be updated. Pass 0×00 if only reading. A value of non-zero will only work if the command is sent via USB.
IP #0: First IP address allowed to connect. A value of 0xFFFFFFFF disables feature.
IP #1: Second IP address allowed to connect.
IP #2: Third IP address allowed to connect.
IP #3: Fourth IP address allowed to connect.
IP #4: Fifth IP address allowed to connect.
