SetDefaults (SetToFactoryDefaults)

Executing this function causes the current or last used values (or the factory defaults) to be stored in flash as the power-up defaults.

The device flash has a rated endurance of at least 20000 writes, which is plenty for reasonable operation, but if this function is called in a high-speed loop the flash could eventually be damaged.

Note: Do not call this function while streaming.

(The values in parenthesis will set the defaults to factory settings.)

Command:



Byte



0

Checksum8

1

0xF8

2

0x01

3

0x0E

4

Checksum16 (LSB)

5

Checksum16 (MSB)

6

0xBA (0x82)

7

0x26 (0xC7)





Response:



Byte



0

Checksum8

1

0xF8

2

0x01

3

0x0E

4

Checksum16 (LSB)

5

Checksum16 (MSB)

6

Errorcode

7

0x00
